Air Source Split Inverter Heat Pump Used For Fan Coils

1. Both 220v and 380v are available.

2. CE approved for full range

3. A+++ ERP approved ( 35 centigrade A+++& 55 Centigrade A++)

4. Mature full dc inverter technology are in used for full range of split type

5. Patented noise reduction technology, very quiet operation.

6. Capacity range from 9kw to 22kw, can suit different apartments and houses.

7. All split type are with full inverter evi technology and the unit can work in low ambient air temperature of -35 centigrade.

8. Used for house heating, cooling and sanitary hot water.



Availability:
Quantity:
Inquire Add to Basket

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

  • Brief Introduction

R32 DC Inverter Air Source Split Inverter Heat Pump Used for Fan Coils, house heating and domestic hot water split type consists of separate indoor unit and outdoor unit, developed with the idea in mind for maximum possible energy saving and maximum low noise level, creatively combines eco-friendly R32 refrigerant, full inverter technology and evi technology with modern design, providing powerful heating and cooling performance and modern elegant design in appearance. HEEALARX air source split full inverter heat pump for fan coils and house heating can provide luxurious house heating cooling solutions for both domestic and office buildings.

R32 Heat pump

Features of HEEALARX Inverter Air Water House Heating Heat Pump Split Type


  • High Efficient A+++ Energy Level Verified by TUV

Targeting the high end European market, our product of air source split type full inverter house heating and cooling heat pump used for fan coils, heating and hot water can be rated A+++ energy label with full inverter evi technology and the excellent product structure and best quality components we are using. With top energy rating A+++ verified by TUV , the unit is with adjustable compressor running capacity from 30%-150%

A+++Air to Water House Heating Heat Pump


  • DC Inverter EVI Technology

The evi technology with full inverter can ensure the optimum performance of air source split inverter heat pump unit when running at low ambient temperature as low as -25 centigrade and even -35 centigrade, which can help to offer the end users with stable comfortable house heating, cooling and hot water supply.

EVI Air Source Heat Pump

  • World Famous Brand Heat Pump Components

As to ensure the stable performance of the air source split inverter heat pump unit, HEEALARX adopts world famous brand  heat pump components such as: ALFA LAVAL Plate heater exchanger, WILO Inverter water pump made in EU, Panasonic R32 full inverter compressor and Panasonic inverter fan motor etc.

Best quality heat pump components

  • Digital Wifi Touch Control

HEEALAX Air Source Split Inverter Heat Pump used for Fan Coils, house heating and hot water equips a full-color control panel and a square gradient effect, highlighting the interface and enhancing the visual impact. The control panel can be detached to used separately, with higher flexibility. Digital touch control with WIFI, can control your heat pump anywhere with app on your smartphone.

WIFI Control Heat Pump

  • R32 Gas

New gas of R32 environment friendly green gas is in use for HEEALARX Air to Water Split Inverter Heat Pump unit,  10%-20% more efficient than R410A and also low carbon consumption.

R32 Inverter Heat Pump

  • Super Low Noise Level Technology

The large-area fan blade is innovatively used in the outdoor unit of HEEALARX air source split inverter heat pump used for fan coils, heating and domestic hot water.Together with a dc inverter fan motor, the noise of the outdoor unit is reduced to even less than  40db and that of the indoor unit is down to 25db. with thanks for using Panasonic full inverter evi type compressor, dc inverter fan motor with changeable fan feed and also well insulation of whole piping and the whole refrigerant system, and the noise level of our heat pump system can reduce to less than 40dB.

Super Silent Heat pump

  •  Mature Full Inverter Technology

After 8 years of research, designing and advancement by our international engineer team from Singapore and China, HEEALARX has fully mastered the secret of the mature full inverter technology and also it has applied to our product of air source split inverter heat pump used for fan coils, heating and domestic hot water.

EVI Heat Pump Water Heater

  • Smart Digital Touch Control

HEEALARX full inverter evi air to water split type house heating heat heat pump has a high-end controller with digital colorful touch screen, which is one of the highlights of this trendy heat pump product. It is incredibly convenient for users from different countries that multi language function can be chosen.

Smart Digital Touch Control

  • Installation

HEEALARX Full inverter evi air water house heating heat pump is designed for house heating, domestic hot water supply and cooling in low ambient air temperature of -25 centigrade to -35 centigrade.



  • Installation Sketch for house heating, domestic hot water and cooling with buffer tank

10


  • Installation Sketch  for domestic hot water and house heating with buffer tank9



Full Inverter Air Water House Heating Heat Pump Split Type
Complete model
VS90-DCSVS120-DCSVS150-DCSVS180-DCSVS220-DCS
External model number
VS90-DCS-FWVS120-DCS-FWVS150-DCS-FWVS180-DCS-FWVS220-DCS-FW
Power Supply/380V～50Hz/3Ph
Heating Condition-Ambient Temp.(DB/WB):7/6℃，Water Temp.(In/Out):40/45℃
Heating Capacity RangekW3.8～9.03.8～11.05.5～15.05.5～17.57.3～21.5
Heating Power Input RangekW0.89～2.480.89～3.061.31～4.111.31～4.851.73～5.91
COP
4.25～3.634.25～3.64.20～3.654.20～3.614.22～3.64
Heating Condition-Ambient Temp.(DB/WB):7/6℃，Water Temp.(In/Out):30/35℃
Heating Capacity RangekW3.7～8.53.7～10.75.2～14.65.2～17.47.0～21.2
Heating Power Input RangekW0.67～1.910.67～2.400.94～3.280.94～3.951.27～4.75
COP
5.55～4.455.55～4.465.56～4.455.56～4.415.52～4.46
Heating Condition-Ambient Temp.(DB/WB):-5/-6℃，Water Temp.(In/Out):36/41℃
Heating Capacity RangekW3.5～7.04.0～8.54.5～13.05.0～15.05.5～17.0
Heating Power Input RangekW0.91～2.331.06～2.851.17～4.301.30～5.981.40～5.45
COP
3.80～3.003.78～2.983.85～3.023.83～3.013.95～3.12
Heating Condition-Ambient Temp.(DB/WB):-12/-13.5℃，Water Temp.(In/Out):36/41℃
Heating Capacity RangekW3.0～6.04.0～7.54.0～11.04.5～13.05.0～15.0
Heating Power Input RangekW1.11～2.451.50～3.061.45～4.401.65～5.301.79～5.88
COP
2.70～2.452.68～2.452.75～2.502.72～2.482.80～2.55
Heating Condition-Ambient Temp.(DB/WB):-20/～℃，Water Temp.(In/Out):～/41℃
Heating Capacity RangekW2.5～5.03.0～6.03.8～9.54.3～11.04.7～12.5
Heating Power Input RangekW1.04～2.331.26～2.791.59～4.441.80～5.191.92～5.68
COP
2.40～2.152.38～2.152.39～2.142.38～2.122.45～2.20
Cooling Condition-Ambient Temp.(DB/WB):35/24℃，Water Temp.(In/Out):12/7℃
Cooling Capacity RangekW2.3～6.52.3～8.03.2～11.03.2～13.04.5～15.0
Cooling Power Input RangekW0.65～2.450.65～3.040.90～4.100.90～4.961.25～5.68
EER
3.53～2.653.53～2.633.55～2.683.55～2.623.6～2.64
ErP Level（35℃）/A+++A+++A+++A+++A+++
SCOP（35℃）/4.814.824.824.804.81
Water Flowm³1.11.41.92.22.6
Refrigerant/Proper InputkgR32/1.2kgR32/1.2kgR32/1.8kgR32/1.8kgR32/2.3kg
Sound Pressure At Rated Flow (1m)dB(A)4243454647
Sound Power LevelEN12102 (35℃)dB(A)5759606162
Cabinet Type/Galvanized sheet+ABS
Compressor Brand/Panasonic
Fan Motor Type/DC motor
Operating Ambient Temperature℃-35～43
Water Connectioninch111.21.21.2
Refrigerant circuit
Liquid Dia(OD):φ9.52  / Gas Dia(OD):φ15.88
Net weightkg657090105115
Unit Dimensions(L/W/H)mm945×440×7501145×440×9501055×440×1400
Shipping Dimensions(L/W/H)mm990×450×9001195×450×11001100×450×1550
The above data is for reference only;specific data is subject to the product nameplate.
